Development Specifications
Technical details of infrastructure and planning standards
Land Allocation Matrix
PHATA NOC covers 903 kanal total area. Land use breakdown: 587 kanal residential (65%), 181 kanal commercial (20%), 90 kanal parks (10%), 45 kanal infrastructure (5%). Grid-pattern planning creates rectangular plots with 40-foot internal roads connecting to 60-foot secondary roads and 120-foot main boulevard. Learn more about our company profile and download detailed development plans.
Road Hierarchy System
Three-tier road network: 120-foot boulevard (4-lane divided), 60-foot secondary roads (2-lane), 40-foot internal streets. Road cross-sections include 8-foot footpaths, 6-foot green belts, street lighting poles at 100-foot intervals, and underground utility corridors for electricity (11KV cables), water (12-inch mains), gas (4-inch pipes), and fiber optic cables.
Underground Utilities
11KV grid station feeds 15 distribution transformers. Water system: 4 deep wells (400-foot depth) with 500,000 gallon overhead tank. Gas network: 4-inch mains with individual meter connections. Sewage: 2 MGD treatment plant using activated sludge process. Fiber optic backbone with 1GB capacity to each plot.
Green Space Network
135 kanal total green area (15% of development). Central park: 25 acres with jogging tracks, exercise stations, children's play areas. Sector parks: 5 acres each with community centers. Linear parks: 20-foot green belts along drainage channels. Plantation includes 15,000 native species and ornamental plants.
Commercial Zone Planning
Commercial areas along 120-foot boulevard and sector centers. Mixed-use buildings permitted ground+3 floors with basement parking mandatory for buildings above 5,000 sq ft. Ground floor retail, upper floors offices/residential. Parking requirement: 1 space per 200 sq ft commercial area.
Security Infrastructure
Perimeter wall: 12-foot height with electric fencing. Controlled access: 3 entry gates with biometric turnstiles. CCTV network: 150 cameras covering all roads and public areas. Security posts: 8 guard posts at 500-foot intervals. Emergency response: direct connection to local police and medical services.
